After multiple rounds of fuzz testing, I discovered that md2roff version 1.9 suffered from a stack buffer overflow vulnerability via a Markdown file containing a large number of consecutive characters to be processed.

Replication

To replicate the vulnerability, download a vulnerable version of md2roff (version 1.9):

git clone https://github.com/nereusx/md2roff.git
cd md2roff
git checkout 9241b8cfeb687c57099f3ef45f03a8ad3f291cf4
make

Once the project is compiled, we can use md2roff to process a malicious markdown file (located here) to replicate a program crash:

./md2roff poc.md

Executing the previous command will result in a segfault:

segmentation fault  ./md2roff poc.md

Compiling the project with address sanitizer (ASAN) can assist in confirming the presence of a stack buffer overflow. To compile the project with ASAN we need to include the ‘-fsanitize=address’ option to the compiler flags (CFLAGS). The resulting Makefile should resemble the following:

#
#       GNU make
#

prefix  ?= /usr/local
bindir  ?= $(prefix)/bin
mandir  ?= $(prefix)/share/man
man1dir ?= $(mandir)/man1

LIBS   = -lc
CFLAGS = -std=c99 -fsanitize=address

all: md2roff md2roff.1.gz

md2roff: md2roff.c
        $(CC) $(CFLAGS) md2roff.c -o md2roff $(LDFLAGS) $(LIBS)

md2roff.1.gz: md2roff.md md2roff
        ./md2roff --synopsis-style=1 md2roff.md > md2roff.1
        -groff md2roff.1 -Tpdf -man -P -e > md2roff.1.pdf
        ./md2roff -z --synopsis-style=1 md2roff.md > md2roff.1
        gzip -f md2roff.1

install: md2roff md2roff.1.gz
        mkdir -p -m 0755 $(DESTDIR)$(bindir) $(DESTDIR)$(man1dir)
        install -m 0755 -s md2roff $(DESTDIR)$(bindir)
        install -m 0644 md2roff.1.gz $(DESTDIR)$(man1dir)

uninstall:
        rm -f $(DESTDIR)$(bindir)/md2roff $(DESTDIR)$(man1dir)/md2roff.1.gz

clean:
        rm -f *.o md2roff md2roff.1*

Once the project is compiled, we can feed our malicious markdown file to md2roff and observe the ‘stack-buffer-overflow’ error thrown by ASAN.

$ ./md2roff poc.md

=================================================================
==15685==ERROR: AddressSanitizer: stack-buffer-overflow on address 0x7ffedb68e230 at pc 0x55ab4ac56d64 bp 0x7ffedb68e020 sp 0x7ffedb68e018
WRITE of size 1 at 0x7ffedb68e230 thread T0
    #0 0x55ab4ac56d63 in md2roff (/home/kali/projects/fuzzing/fuzz_targets/md2roff/md2roff+0x10d63)
    #1 0x55ab4ac598c0 in main (/home/kali/projects/fuzzing/fuzz_targets/md2roff/md2roff+0x138c0)
    #2 0x7f589f446189 in __libc_start_call_main ../sysdeps/nptl/libc_start_call_main.h:58
    #3 0x7f589f446244 in __libc_start_main_impl ../csu/libc-start.c:381
    #4 0x55ab4ac4d3a0 in _start (/home/kali/projects/fuzzing/fuzz_targets/md2roff/md2roff+0x73a0)

Address 0x7ffedb68e230 is located in stack of thread T0 at offset 80 in frame
    #0 0x55ab4ac50d7e in md2roff (/home/kali/projects/fuzzing/fuzz_targets/md2roff/md2roff+0xad7e)

  This frame has 6 object(s):
    [32, 40) 'tt' (line 724)
    [64, 80) 'num' (line 1140) <== Memory access at offset 80 overflows this variable
    [96, 352) 'secname' (line 662)
    [416, 672) 'appname' (line 662)
    [736, 992) 'appsec' (line 662)
    [1056, 1312) 'appdate' (line 662)
HINT: this may be a false positive if your program uses some custom stack unwind mechanism, swapcontext or vfork
      (longjmp and C++ exceptions *are* supported)
SUMMARY: AddressSanitizer: stack-buffer-overflow (/home/kali/projects/fuzzing/fuzz_targets/md2roff/md2roff+0x10d63) in md2roff
Shadow bytes around the buggy address:
  0x10005b6c9bf0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c00: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c20: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c30: 00 00 00 00 00 00 00 00 00 00 00 00 f1 f1 f1 f1
=>0x10005b6c9c40: f8 f2 f2 f2 00 00[f2]f2 00 00 00 00 00 00 00 00
  0x10005b6c9c50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c60: 00 00 00 00 00 00 00 00 f2 f2 f2 f2 f2 f2 f2 f2
  0x10005b6c9c70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x10005b6c9c90: f2 f2 f2 f2 f2 f2 f2 f2 00 00 00 00 00 00 00 00
Shadow byte legend (one shadow byte represents 8 application bytes):
  Addressable:           00
  Partially addressable: 01 02 03 04 05 06 07
  Heap left redzone:       fa
  Freed heap region:       fd
  Stack left redzone:      f1
  Stack mid redzone:       f2
  Stack right redzone:     f3
  Stack after return:      f5
  Stack use after scope:   f8
  Global redzone:          f9
  Global init order:       f6
  Poisoned by user:        f7
  Container overflow:      fc
  Array cookie:            ac
  Intra object redzone:    bb
  ASan internal:           fe
  Left alloca redzone:     ca
  Right alloca redzone:    cb
  Shadow gap:              cc
==15685==ABORTING

Attaching GDB to md2roff (gdb ./md2roff) and executing the malicious markdown file reveals useful information that can be used to find the exact location of the overflow:

From the GDB output, the vulnerable source code can be traced back to the function void md2roff(const char *docname, const char *source) around lines 1387 through 1392. .

Vulnerable source code:

 else if ( isdigit(*p) ) { // ordered list
   char    num[16], *n;
   const char *pstub = p;

   n = num;
   while ( isdigit(*p) )
     *n ++ = *p ++;
   *n = '\0';

In addition to finding the vulnerable source code, we can observe that the return pointer was successfully overwritten by our malicious markdown file

References

• https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2022-41220
• https://owasp.org/www-community/vulnerabilities/Buffer_Overflow
